Power Electric Motors

Name: Power Electric Motors
Brand: WILSON INDUSTRIES
Price: 1 INR
Availability: InStock

Price 1 INR/ Piece

Get a Price/Quote

MOQ : 5 Pieces

Power Electric Motors Specification

Horse Power
2 HP

Features
High Efficiency, Low Maintenance, Robust Construction

Torque
9.95 Nm

Cooling Method
Air Cooled

Current Type
AC

Power Rating
1.5 kW

Ambient Temperature
-15C to 50C

Voltage
415 V

Sealed Type
IP55 Sealed

Motor Type
Induction Motor

Poles Number
4

Efficacy
IE2 High Efficiency

Starting Type
DOL

Standard
IS 325

Rated Frequency
50 Hz

Noise Level
<60 dB

Bearing Type
Double Sealed Ball Bearing

Rated Voltage
415 V

Product Type
AC Electric Motor

Output Power
2 HP

Frequency (MHz)
50 Hz

Protect Feature
Totally Enclosed

Phase
Three Phase

Speed
1440 RPM

Power
1.5 kW

Color
Blue-Grey

Dimension (L*W*H)
360 x 230 x 260 mm

Weight
30 kg

Shaft Diameter
28 mm

Mounting Type
Foot Mounted

IP Rating
IP55

Insulation Class
F Class

Rotor Type
Squirrel Cage

Service Factor
1.15

Output Shaft Length
60 mm

Duty Type
S1 (Continuous Duty)

Suitable For
Industrial & Agricultural Applications

Frame Size
112M

Material
Cast Iron Body

Thermal Protection
Yes

Power Electric Motors Trade Information

Minimum Order Quantity
5 Pieces

FOB Port
ahemdabad

Supply Ability
400 Pieces Per Day

Delivery Time
1 Week

Packaging Details
wooden boxes

Main Domestic Market
All India

Certifications
iso certified

About Power Electric Motors

Power electric motors offer great efficiencies in many applications. Here the driving force is torque. The motors are engineered for load capabilities and energy savings. They have proven design and construction for an optimized performance. With quality components and core technology, we offer excellent power electric motors. They are engineered for easy installation and simple maintenance. The motors are perfect in mechanical seal, packing, and suited for wide voltage. They are practical in petroleum, power plants, chemicals, construction, manufacturing, and other industrial. We bring lightweight, efficient and high-power electric motors.

Product details

Power	2 HP
Brand	Wilson
Speed	2000 RPM
Type	AC
Phase	Single
Material	Mild Steel
Usage/Application	Industrial
Country of Origin	Made in India

Rugged Efficiency for Demanding Environments

Built to withstand challenging industrial and agricultural settings, this motor features a robust cast iron body, high IP55 sealing, and F Class insulation. Its efficient IE2 design and double sealed ball bearings reduce downtime, while continuous S1 duty ensures non-stop reliability in heavy workloads.

Precision Engineering and Safety Features

With a precise output shaft, foot mounting, and thermal protection, the motor meets IS 325 standards for safety and performance. The air-cooled system maintains stable temperatures, and the low <60 dB noise level creates a safer, quieter workspace.

FAQs of Power Electric Motors:

Q: How does the insulation class F benefit the motors performance?

A: Insulation Class F allows the motor to withstand higher operating temperatures, ensuring longevity and improved reliability during continuous operation in demanding industrial and agricultural applications.

Q: What is the process for installing this motor in industrial applications?

A: To install, securely foot-mount the motor using the designated frame, connect the three-phase 415V power supply via DOL starter, and ensure proper alignment of the output shaft with your equipment. The IP55 protection and double sealed bearings guarantee reliable operation even in harsh environments.

Q: When should thermal protection features be utilized?

A: Thermal protection is an integral feature designed to safeguard the motor from overheating. It automatically activates if unsafe temperatures are detected, making it essential whenever the motor operates under continuous or high-load conditions.

Q: Where is this electric motor most effectively used?

A: This model is ideal for industrial processing plants and agricultural operations requiring continuous, high-efficiency performancesuch as irrigation systems, conveyors, pumps, and fans.

Q: What are the primary benefits of choosing a motor with an IE2 high efficiency rating?

A: IE2 high efficiency reduces operating costs through lower power consumption and generates less heat, resulting in an environmentally friendly, cost-effective, and longer-lasting motor solution.

Q: How does the totally enclosed IP55 rating enhance motor durability?

A: The IP55 totally enclosed rating ensures protection against dust and water jets, minimizing maintenance needs and extending the life span of the motor, even in demanding or outdoor conditions.
