Vibrator Induction Motors

Get a Price/Quote

MOQ : 5 Pieces

Vibrator Induction Motors Specification

Sealed Type
Double Sealed Bearing

Motor Type
Vibrator Induction Motor

Rated Voltage
415 V

Power Rating
As per Model

Horse Power
0.25 HP to 30 HP

Cooling Method
Surface Cooling (IC 411)

Noise Level
Low Noise

Bearing Type
Heavy Duty Ball Bearing

Rated Frequency
50 Hz

Starting Type
Direct On Line (DOL) / Star Delta

Poles Number
2 / 4 / 6 / 8 Poles

Efficacy
IE2 / High Efficiency

Torque
High Starting Torque

Pressure
Ambient Pressure

Ambient Temperature
Up to 50C

Current Type
AC

Voltage
415 V

Standard
IS:325, IEC:60034

Features
Low Vibration, Sturdy Construction, Reliable Output

Product Type
Vibration Motor

Output Power
0.18 kW to 22 kW

Frequency (MHz)
50 Hz

Protect Feature
Totally Enclosed, Dust & Water Proof

Phase
Three Phase

Speed
750 - 3000 RPM

Power
Custom Range

Color
Blue / Green

Dimension (L*W*H)
As per model specification

Weight
Variable (According to model)

Shaft Diameter
As per Standard

Mounting Type
Foot Mounting / Flange Mounting

IP Rating
IP55

Cable Entry
Double Cable Entry

Frame Size
63 to 160 mm

Enclosure Type
Totally Enclosed Fan Cooled (TEFC)

Duty Type
S1 Continuous Duty

Vibration Force
3 kN to 250 kN

Insulation Class
Class F (Standard), Class H (Optional)

Surface Finish
Corrosion Resistant Paint

Mounting Pattern
As per IEC Standards

Vibrator Induction Motors Trade Information

Minimum Order Quantity
5 Pieces

FOB Port
ahemdabad

Supply Ability
400 Pieces Per Day

Delivery Time
1 Week

Packaging Details
wooden boxes

Main Domestic Market
All India

Certifications
iso certified

About Vibrator Induction Motors

We offer high-efficient vibrator induction motors for varied applications. They are also called vibratory motor, vibro motor, unbalance motor, etc. The vibration helps in applications like compacting, assorting, conveying etc. These motors are designed for safety, continuous operation and proven performance. They can work in all conditions and at high-ambient temperatures. The motors offer an extended voltage range. They are excellent in protection, insulation, rotor, and other concepts. Vibrator induction motors are used in food industries, mining, construction, ceramic, foundry, plastic and recycling industries.

Product details

No Of Phase	Three Phase
Rated Power	15 HP
Brand	Wilson
Speed	1500 RPM
IP Rating	IP21
No Of Poles	2
Mounting Type	Foot Mount
Insulation Class	Type B
Usage/Application	Industrial
Material	Mild Steel
Country of Origin	Made in India

Versatile Frame Sizes and Power Options

These vibrator induction motors offer a wide selection of frame sizes from 63 to 160 mm, with output power ranging from 0.18 kW to 22 kW. This adaptability ensures suitability for a broad spectrum of industrial vibration applications, from light conveying to heavy-duty material separation.

Superior Durability and Protection

Constructed with a corrosion-resistant surface and totally enclosed fan cooled (TEFC) enclosure, these motors provide long-term durability. With an IP55 dust and water proof rating and double-sealed bearings, the motors are designed to perform reliably in demanding environments, safeguarding internal components against contamination.

High Efficiency and Performance

Certified to IS:325 and IEC:60034 standards, these motors feature IE2 high efficiency, low vibration, and high starting torque. Continuous S1 duty and advanced surface cooling (IC 411) enable prolonged, reliable operation with minimal noise, aligning with industrial efficiency and productivity requirements.

FAQs of Vibrator Induction Motors:

Q: How are vibrator induction motors typically installed?

A: Vibrator induction motors are mounted following IEC standardized patterns, supporting both foot and flange mounting methods. This flexibility facilitates straightforward integration into existing or new industrial systems.

Q: What benefits do the TEFC enclosure and corrosion-resistant finish provide?

A: The Totally Enclosed Fan Cooled (TEFC) enclosure paired with a corrosion-resistant paint ensures protection from dust, water, and harsh environmental conditions, resulting in increased lifespan and reduced maintenance for the motor.

Q: When should I choose Class F over Class H insulation?

A: Class F insulation is the standard and suits most operating conditions. For environments with higher ambient temperatures or exceptionally demanding thermal requirements, selecting Class H insulation offers extra thermal resilience.

Q: Where can these motors be used most effectively?

A: These motors are ideal for industries such as mining, food processing, foundries, concrete, and other sectors where reliable vibration is needed for material conveying, sifting, or compaction under harsh or outdoor conditions.

Q: What is the process for connecting these motors to power?

A: The motors are configured for three-phase AC operation at 415V/50Hz. Starting can be achieved via Direct On Line (DOL) or Star-Delta configurations, depending on the applications requirements and power rating.

Q: What makes these motors suitable for continuous duty applications?

A: The S1 continuous duty rating, efficient cooling (IC 411), high starting torque, and heavy-duty ball bearings enable persistent running under load without overheating, making them ideal for uninterrupted industrial operation.
